Factory Lead Time

6 Weeks

Lifecycle Status

ACTIVE (Last Updated: 5 days ago)

Package / Case

515-WFBGA, FCBGA

Mounting Type

Surface Mount

Mount

Surface Mount

Number of Pins

515

Number of I/Os

188

Memory Types

FLASH

Series

TMS320DM37x, DaVinci™

Packaging

Tray

Operating Temperature

-40°C~90°C TJ

JESD-609 Code

e1

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

515

ECCN Code

5A992.C

Type

Digital Media System-on-Chip (DMSoC)

Terminal Finish

Tin/Silver/Copper (Sn/Ag/Cu)

Terminal Position

BOTTOM

Terminal Form

BALL

Peak Reflow Temperature (Cel)

260

Supply Voltage

1.14V

Frequency

1GHz

Base Part Number

DM3725

Pin Count

515

Operating Supply Voltage

1.8V

Power Supplies

1.23.3V

Interface

1-Wire®, EBI/EMI, I²C, McBSP, McSPI, MMC/SD, UART, USB, USB OTG

Memory Size

32kB

Speed

1000 MHz

RAM Size

64kB

Bit Size

32

Data Bus Width

32b

Core Architecture

ARM

Boundary Scan

YES

Low Power Mode

YES

Format

FLOATING POINT

Integrated Cache

YES

Voltage - I/O

1.80V

Number of UART Channels

4

Voltage - Supply (Max)

1.91V

Voltage - Supply (Min)

1.71V

Non-Volatile Memory

ROM (32kB)

Voltage - Core

1.10V

On Chip Data RAM

384kB

Height

700μm

Width

12mm

Length

12mm

Thickness

500μm

RoHS Status

ROHS3 Compliant

Radiation Hardening

No

Lead Free

Lead Free
